Specifications

General:

EFUEL Article no:

AMINA S Charger 20A + Enegic Powerlink Monitor One: E408
AMINA S Charger 20A + Enegic Powerlink Monitor: E409
AMINA S Charger 32A + Enegic Powerlink Monitor One: E413
AMINA S Charger 32A + Enegic Powerlink Monitor: E414

Specifications Amina S:

Manufacturer: Amina
Manufacturer warranty: 5 years
Color: Black
Surface: Matt
Material: Polypropylene, PP
Charging cable: Mode 3 and fixed type 2 (20A/32A)

Dimensions and weight:

Dimensions: Height 264 mm, width 112 mm and depth 89 mm
Weight: 1 kg excl. charging cable, 2.4 kg (20 A) and 3.4 kg (32 A)

Power and connectivity:

Standards and approvals: Low power wireless mesh network
Max. current and charging 20A cable: Current: 6-20 A; 3-phase output: 3.7 - 13.8 kW; 1-phase output: 1.4- 4.6 kW
Integrated earth fault protection: RDC-DD (6 mA DC) according to IEC 62955
Standards and approvals: 2.4 GHz radio
Max. current and charge 32 A cable: Current: 6-32 A 3-phase; power: 3.7 - 22.0 kW 1-phase; power: 1.4 - 7.4 kW
Energy measurement: Integrated 3-phase energy measurement with +/- 3% accuracy
Degree of protection: IP54: indoor and outdoor use; IK08: shock protection UL94-5VB: flammability classification; UV resistant
Electrical protection: Protection class I (4 kV AC and 6 kV impulse, insulation); Overvoltage category III (4 kV)

Standards and approvals:

Radio Equipment Directive 2014/53/EU (RED) RoHS Directive 2011/65/EU
BS EN IEC 61851-1:2019
IEC 62955:2018 (RDC)
BS EN 92196-2:2017 - TC
BS EN IEC 61851-21-2:2021

Contents of the box:

Back plate
Charging unit
Front cover
Charging cable (20 A/32 A)
Mounting kit

Required for installation:

TX20 screwdriver
Circuit breaker switch
External earth leakage switch Type A

Pleasenote that the communication between the Hub and Monitor/Monitor One is via the cloud, which means that only a stable internet connection is required for data to be sent between the devices. There is therefore no maximum distance between Monitor/Monitor One and Hub to take into account.

However, communication between the Hub and the amina S is via Bluetooth. In this case, the Hub therefore needs to be installed within 20 meters of the amina S charging station to ensure secure communication.

Material

amina

S + Enegic Powerlink

The amina S + Enegic Powerlink product bundle ensures reliable and safe charging experiences for both regular and smart homes. Amina S is a fast and smart charging box that provides total control over charging speed and electricity consumption. Powerlink is Enegic's solution for EV charging with Amina S.

With Powerlink, we don't just offer dynamic load balancing - we control the entire charging box. Without any middleman, Powerlink is our most advanced and stable solution for EV charging, load balancing and power control. With Powerlink, you measure and monitor the property's power output and electricity consumption in real time. In properties with solar panels, Powerlink also provides invaluable information about sold/produced electricity, directly in the app.

To work with both P1/RJ12 and L1, L2, L3, Powerlink is developed in two versions - both equally easy to install. Save money and charge safely with Powerlink.
